Laser welding cleaning machine wiring instructions(1000W-2000W)

To ensure proper operation of this machine, please use only appropriately sized and rated power cables and connectors. Insufficient power supply may result in reduced performance, malfunction, or damage to the equipment.

Wiring Requirements: this instruction is applicable to 1500W/2000W laser

  • Direct Connection:High-power laser welders require fixed wiring to circuit breakers instead of plugs to ensure stability and compliance with standards like IEC 60309 (industrial connectors).
  • Power cord: 6m² (Copper wire)/10AWG
  • Circuit breaker: 63A

Note: Cannot be directly connected to the generator, need to connect a voltage stabilizer after the generator.

1500W 2000W Laser welding cleaning machine wiring instructions

Consult a qualified electrician if unsure about the power requirements.

Consequences of Non-Compliance:
Partial functionality or complete failure of the machine(No laser response or water chiller status alert E08 error).
Risk of overheating, electrical damage, or fire hazards.

For Your Safety:
Always follow local electrical codes and regulations when installing or connecting power supplies.
