Metal Laser Cutting Machine TR-F6060
High-performance laser cutting machine 600x600mm

Metal Laser Cutting Machine

The fiber metal laser cutting machine series are metal precise processing equipment powered by fiber laser technology. The quality fiber laser beam results in faster cutting speeds and higher quality cuts compared to other cutting solutions.

The heavy bed makes the metal sheet fiber laser cutting machine more stable in working;

The light crossbeam makes it work faster; perfect industrial design is more in line with man-machine engineering;

High quality electrical software control system gives equipment higher cutting precision;

The machine owns more comfortable operation, more stable performance, more durable quality;

Higher cutting efficiency and wider application scope.

Application

Applicable materials:Used for cutting gold,silver,carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy,galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.

Applicable industries:Applied in high precision apparatuses,aluminum copper clad laminates， machinery, electrical apparatuses, metal crate and cabinet, electric appliance shell, metal plate processing,sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.

fiber laser cutting metal samples 061315

fiber laser cutting metal samples 061308

fiber laser cutting metal samples 061311

fiber laser cutting metal samples 061305

fiber laser cutting metal samples 061312

fiber laser cutting metal samples 061309

fiber laser cutting metal samples 061310

fiber laser cutting metal samples 061314

Videos of TR-F6060

Technical Parameters

Model	TR-F6060
Working Area	600mmX600mm (23.6″×23.6″)
Laser Power	1000W/1500W/2000W/3000W
Max.Cutting Speed	40m/min
Max. accelerated	1G
X/Y-axis positioning accuracy	0.02mm
Power supply	220V / 50Hz (110V/60Hz)
Transmission	Precise pinion and rack,dual-drive transmitting
Machine Size	180×145×182cm(70.87″×57.10″×71.65″)
Package Size	191×167×203cm(75.2″×65.75″×79.92″)
Gross Weight	1350kg

Fiber Laser Series

We have multiple series of fiber lasers for choice,such as MAX fiber laser series,Raycus fiber laser series.

The fiber lasers has higher electro-optical conversion efficiency, higher and more stable optical quality, stronger altitude stress-resisting capacity and it applies optimized second-generation fiber transmission system to ensure more stable and more sophisticated cutting effect in thick sheet cutting. fiber lasers applies to many application scenarios: cutting, welding, holing, medical device processing, etc., with a narrow seam of the cut sheet and bright section.

HighElectro-optical Conversion Efficiency
Altitude Stress-resisting Capacity
Sheet Cutting Efficiency
Customized Output Fiber Length
Maintenance-freeOperation
Wide Modulation Frequency Range

Raytools Laser Head Series

The laser head made in Swiss is suitable for fiber laser cutting machine, with a diversified interface setting so that it can be matched with all kinds of mainstream fiber lasers. The cutting head adopts the optimization of optical design, light weight, small volume, easy to use, with a height sensor can make cutting more efficient, but low price,which is preferred for cutting equipments with fiber laser cutting machine.
Auto – focus:Applicable to various focal lengths, which are controlled by machine tool control system. Focal point will be automatically adjusted in cutting process to achieve the best cutting effect of different thicknesses sheets metal.
Accuracy:Increasing perforation focus length, separately setting perforation focal length and cutting focal length, enhance cutting accuracy.

Raytools laser cutting head BT210S:(Rated Power)≤1500W
Raytools laser cutting head BM109:(Rated Power)1500W
Raytools laser cutting head BT240S:(Rated Power)3000W
Raytools laser cutting head BM114S:(Rated Power)6000W

OSPRI Laser Head Series

OSPRI laser head is a auto-focus cutting head，which is featured by its fast speed of focusing, high accuracy, user-friendly operation, compact structure and light weight.
Additionally, the built-in auto edge-searching sensor can facilitate the users to position the sheets. Patented design of dust-proof collimating protective window can better protect the optical parts inside the head and extend the service lifespan.
It can not only monitor the temperature of all optical lenses inside the laser head in real time, but also monitor the air leakage, piercing conditions etc. All the feedback information will be uploaded to PC and mobile APP in real time.

OSPRI laser cutting head LC209:(Rated Power)2KW/4KW
OSPRI laser cutting head LC208:(Rated Power)≤4KW
OSPRI laser cutting head LC608:(Rated Power)≤6KW～≤12KW
OSPRI laser cutting head LC808:(Rated Power)8KW

Laser Control System

The operating system can realize intelligent layout of graphics cutting and support the import of multiple graphics, optimizing cutting orders automatically, searching edges smartly and automatic positioning.
Control system adopts the best logic programming and software interaction, provides stunning operation experience, effectively enhancing the utilization of sheet metal and reducing waste. Simple and fast operation system, efficient and accurate cutting instructions, effectively improve the user experience.

Gear Rack Drive System

Equipped with grinding gear and rack, and through the precision collimator one time metering assembly. Secure high cutting speed, high precision transmission.instructions, effectively improve the user experience.

Server System

The fiber laser machine adopts the imported servo system from japan including servo motor and servo driver,The electric and drive systems provided by Japan Fuji Electric offer customers a faster rotation speed and better stability.
